UF Series UF30 309048MM Freewheel Clutch One Way Bearings Factory

Name: UF Series UF30 309048MM Freewheel Clutch One Way Bearings Factory
Brand: SUMA
Price: 25 USD

Brand Name : SUMA

Model Number : UF30

Certification : ISO SGS

Place of Origin : CHINA

MOQ : 5pcs

Price : USD25-USD40 PER PIECE

Payment Terms : L/C, D/A, D/P, T/T, Western Union, Paypal

Supply Ability : 1000PCS Per Month

Delivery Time : 10-15 Days

Packaging Details : Carton Box

Product Name : Freewheel Clutch One Way Bearings

Material : GCr15 Bearing Steel

Rotation Speed : 2100RPM

Unit Weight : 1.6Kg

Warranty : 1 Year

Size : 30*90*48MM

Torque Capacity : 500Nm

OEM : Accept

MOQ : 5-

Contact Now

UF Series UF30 30*90*48MM Freewheel Clutch One Way Bearings Factory

Features of Freewheel Clutch One Way Bearings

The UF Series freewheels are not self- centering. It is therefore necessary to place one or two bearings next to the freewheel so that the outer race can rotate centrally to the inner race

The torque forces are transmitted from the shaft to the inner race by means of a key and from the outer race to the seating by means of front pullers.

Shaft tolerance must be either h6 or j6; the tolerances for the seating must be either H7 or G7. When front pullers are not used, the seating tolerance should be K6.

Before being put onto service, the freewheels must be lubricated with suitable lubricants following the instructions given on page 12. Oil lubrication is essential when a high number of rotations in neutral is reached.

Dimensions and Capacities of Freewheel Clutch One Way Bearings

Type	Size		Overrunning speeds								Weight
UF	d^H7	T_KN¹)	n_imax²)	n_amax³)	D_n6	D₅	D₆	L	t	b^H11
	[mm]	[Nm]	[min-1]	[min-1]	[mm]	[mm]	[mm]	[mm]	[mm]	[mm]	[kg]
	8	20	5000	6000	37	30	20	20	3	6	0.1
	12	20	5000	6000	37	30	20	20	3	6	0.1
	15	78	4500	5400	47	37	26	30	3.5	7	0.3
	20	188	3000	3600	62	52	37	36	3.5	8	0.6
	25	250	2200	2600	80	68	49	40	4	9	1.1
	30	500	1800	2100	90	75	52.5	48	5	12	1.6
	35	663	1600	1950	100	80	58	53	6	13	2.3
	40	1100	1250	1700	110	90	62	63	7	15	3.1
	45	1500	1100	1500	120	95	69	63	7	16	3.7
	50	2375	850	1300	130	110	82	80	8.5	17	5.4
	55	2500	800	1200	140	115	83	80	9	18	6.1
	60	4250	700	1100	150	125	93.5	95	9	18	8.5
	70	5875	620	900	170	140	106	110	9	20	13
	80	10000	550	800	190	160	122	125	9	20	18
	90	17250	480	700	215	180	133	140	11.5	24	25.3
	100	19625	400	600	260	210	157	150	14.5	28	42.1
	130	34750	300	480	300	240	188	180	17	32	65
	150	44375	250	400	320	260	205	180	17	32	95

NOTES

1) T max = 2 × T KN

» Refer to Selection page 10 to 13

2) Inner race overruns

3) Outer race overruns

Mounting and Coupling

UF Series UF30 30*90*48MM Freewheel Clutch One Way Bearings Factory

Pictures
